100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

Product Categories
Guangzhou Juchuan Machinery Co., Ltd.
Contact Now

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

Place of Origin : Guangdong, China

Model Number : VI-AO

Brand Name : JuChuan

Certification : CE ISO9001

Supply Ability : 100 Unit/Units per Month

Price : $34,567.00 - $43,567.00/sets

MOQ : 1set

Payment Terms : L/C, T/T, Western Union

Delivery Time : 15 - 20 working days

Packaging Details : container

Condition : New

Style : VERTICAL

Clamping Force : 50~1000Ton

Type : Injection molding machine

After-sales Service Provided : Engineers available to service machinery overseas

Plastic Type : Thermoplastic

Power : 16.90~64.5Kw

Injection Rate : Adjustable

Automatic : Yes

Injection Weight : 500~10000cc

Clamp Force(Ton) : 50~1000

Injection Volume(cc) : 500~10000

Injection Pressure(kgf/xm2) : 1800

Platen Size(mm) : 300*300~1200*1200

Plunge Stroke(mm) : 300~500

Heater Capacity(kw) : 8.4~42

Gross Weight(Ton) : 5.5~21

Port : Guangzhou

clamp force : 50-1000

injection volume : 500-4000

injection pressure : 1800

plunger stroke : 300-500

opening mold : 2RT3RT4RT

Gross weight : 5.5-10ton

Contact Now

100-1000T Energy-Saving Used Aluminum Injection Machine

VI-AO Series Vertical "all-in-out" Silicone/Ssynthetic Rubber Injeciton Molding Machine

Key Features:

1. Versatile Application: The machine is well-suited for automotive and electronic rubber parts, high/cold temp precision rubber parts, with a special focus on NBR products.

2. All-in-Out Structure: Featuring a sprueless injection process, the machine ensures minimal material loss and allows for precise control of the injecting material temperature.

3. High Precision Molding: The machine excels in producing high precision molded parts, achieving 5-10 times better accuracy compared to conventional injection machines. It can achieve a measuring precision of ±0.1 g for a 1000cc injection volume.

4. Anti-Collision Molding System: A patented system is in place to prevent mold damage resulting from misalignment, ensuring smooth and reliable operation.

5. Energy-Efficient: The machine is equipped with a Servo-Controlled system, which can lead to energy savings of up to 40% during operation.

6. Proportional Backpressure Control: The machine features a proportional backpressure controlling characteristic, ensuring optimal molding conditions and enhancing the overall efficiency of the process.

Model Unit 50VI-AO 100VI-AO 200VI-AO 300VI-AO 400VI-AO 600VI-AO 800VI-AO 1000VI-AO
Clamping Force Ton 50 100 200 300 400 600 800 1000
Injection Capacity cc 500 500 2000 3000 4000 6000 8000 10000
Injection pressure kgf/cm² 1800 1800 1800 1800 1800 1800 1800 1800
Operation table size mm 300*300 400*400 550*560 700*700 700*700 850*850 1000*1000 1200*1200
Min. Mold Thickness mm 50 50 100 100 100 100 150 150
Plunger stroke mm 300 350 400 400 400 500 500 500
Distance of Thermo-plate mm 350~450 400~500 500~600 500~600 500~600 600~700 650~800 650~800
Distance of Tie bar mm 400*140 515*230 640*310 820*395 820*395 970*500 1140*600 1340*800
Die sinking type 2RT-3RT-4RT-Upper Mold-Lower Mold

Max. Operating

Pressure

 Mpa 20 20 20 20 20 20 20 20
Motor Power hp 7.5 10 15 15 15 20 20 25

Electric Heating Power

 Kw 8.4 10 15.3 24 24 29.75 35 42
Total Power Kw 16.9 20.5 30.3 39 39 48.75 54 64.5
Gross weight Ton 5.5 6 7.5 9 10 14.2 17.5 21

Dimension

(L*W*H)

 mm

2000*1500

*H2800

2400*1650

*3200

2600*2000

*4000

2750*2265

*4200

2750*2265

*4200

3200*2500

*4350

L3450*W2750

*H4500

3750*3050

*5000

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

Product Features

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

Application

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine 100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine 100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine
Company Information

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

FAQ

100T-1000T Silicone Injection Molding Machine Rubber Product Making Machine

If you have any queries and suggestions, please feel free to let us know:

Tel/Watapp:0086-020-34812609
